Hikvision
Hikvision DS-2CD1363G2-LIUF/SL
Rs 15,800
6 MP Smart Hybrid Light Fixed Turret Network Camera
- High quality imaging with 6 MP resolution
- Support Human and Vehicle Detection
- Smart Hybrid Light: advanced technology with long range
- Efficient H.265+ compression technology
- Support on-board storage up to 512 GB (SD card slot)
- Provide real-time security via built-in two-way audio
- Water and dust resistant (IP67)
Need a spec check, a bulk price or installation with it? Send an enquiry about this product
- 100% original — 2 Years Official Warranty
- Free delivery over Rs 10,000 — cash on delivery available
- Installation available — call Asad on 0324-4298577
Specifications & details
- Camera
- Image Sensor 1 / 2.4″ Progressive Scan CMOS
- Max. Resolution 3200 × 1800
- Min. Illumination Color: 0.005 Lux @ (F1.6, AGC ON) ,B/W: 0 Lux with IR
- Shutter Time 1 / 3 s to 1 / 100,000 s
- Day & Night IR cut filter
- Angle Adjustment Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
- Lens
- Lens Type Fixed focal lens, 2.8 and 4 mm optional
- Focal Length & FOV 2.8 mm, horizontal FOV 105°, vertical FOV 55°, diagonal FOV 127°
- Lens MountM 12
- Iris Type Fixed
- Aperture F1.6
- DORI
- DORI 2.8 mm, D: 76 m, O: 30 m, R: 15 m, I: 7 m
- Illuminator
- Supplement Light Type IR,White Light
- Supplement Light Range Up to 30 m
- Smart Supplement Light Yes
- IR Wavelength 850 nm
- Video
- Main Stream
50 Hz:
20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub-Stream
50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
- Video Compression
Main stream: H.265+ / H.265 / H.264+ / H.264,
Sub-stream: H.265 / H.264 / MJPEG
- Video Bit Rate 32 Kbps to 1 6 Mbps
- H.264 Type Base line Profile ,Main Profile ,High Profile
- H.265 Type Main Profile
- Bit Rate Control CBR,VBR
- Region of Interest (ROI) 1 fixed region for main stream
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Audio
- Audio Type Mono sound
- Audio Sampling Rate 8 kHz / 16 kHz
- Environment Noise Filtering Yes
- Audio Compression G.711 / G.722.1 / G.726 / MP2L2 / PCM / AAC-LC
- Audio Bit Rate 64 Kbps (G.711 l aw / G.711alaw) / 16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
- Network
- Security Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
- Simultaneous Live View Up to 6 channels
- API Open Network Video Interface (Profile S, Profile T, Profile G),ISAPI,SDK
- Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- Client iVMS-4200,Hik-Connect
- Web Browser
Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Fire fox 52.0+, Edge 89+
- Image
- Wide Dynamic Range (WDR)120 dB
- SNR ≥ 52 dB
- Day / Night Switch Day ,Night ,Auto ,Schedule
- Image Enhancement BLC,HLC,3D DNR
- Image Settings Rotate mode ,saturation ,brightness ,contrast ,sharpness ,gain ,white balance ,adjustable by client software or web browser
- Privacy Mask 4 programmable polygon privacy masks
- Interface
- Ethernet Interface1 RJ45 10 M / 100 M self-adaptive Ethernet port
- On-Board Storage
Built-in memory card slot, support microSD / micro SDHC / micro SDXC card, up to 512 GB
- Built-in Microphone Yes,1 built-in microphone
- Built-in Speaker Max. power consumption: 1.5 W, max. sound pressure level: 10 cm: 95 dB.
- Reset Key Yes
- Event
- Basic Event Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm ,exception
- Linkage Upload to FTP / NAS / memory card, notify surveillance center ,send email, trigger recording, trigger capture, audible warning, flashing light
- General
- Power
12 VDC ± 25%, 0.66 A, max. 8 W,Ø5.5 mm coaxial power plug ,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 9.5 W
- Material Metal & Plastic
- Dimension Ø 110 mm × 102.7 mm (Ø4.33″ × 4.04″)
- Package Dimension150 mm × 150 mm × 141 mm (5.9″ × 5.9″ × 5.6″)
- Weight Approx. 340 g (0.7 lb.)
- With Package Weight Approx. 560 g (1.2 lb.)
- Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Language English, Ukrainian
- General Function Heartbeat ,anti-banding ,mirror, password protection ,password reset via email
- Flashing Light Yes
- Protection IP67: IEC 60529-2013
