Hikvision
Hikvision DS-7608NI-Q1(E)
Rs 21,000
8-ch 1U Q Series NVR
- Up to 8-ch IP camera inputs
- H.265+/H.265/H.264+/H.264 video formats
- Up to 2-ch@8 MP/4-ch@4 MP/8-ch@1080p decoding capacity
- Up to 80 Mbps incoming bandwidth
Need a spec check, a bulk price or installation with it? Send an enquiry about this product
- 100% original — 2 Years Official Warranty
- Free delivery over Rs 10,000 — cash on delivery available
- Installation available — call Asad on 0324-4298577
Specifications & details
- Motion Detection 2.0
- Human/Vehicle Analysis 4-ch
- Video and Audio
- IP Video Input 8-ch
- Incoming Bandwidth 80 Mbps
- Outgoing Bandwidth 80 Mbps
- HDMI Output 1-ch, 4K (4096 × 2160)/30Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/30Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- VGA Output 1-ch, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1280×720 /60Hz
- Video Output Mode HDMI/VGA simultaneous output
- Audio Output 1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 k Ω)
- Recording
- Stream Type Video, Video & Audio
- Audio Compression G.711ulaw/G.711alaw/G.722/G.726
- Decoding
- Decoding Format H.265+,H.265,H.264+,H.264
- Recording Resolution 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
- Decoding Capability
AI&4K Off: 8-ch@1080p(30fps)
AI/4K On: 6-ch@1080p(30fps)
*: The length or width of camera resolution (each track) cannot exceed 4096 pixels.
- Synchronous playback8-ch
- Network
- Remote Connection 32
- Network Protocol TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
- Network Interface 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface
- Auxiliary Interface
- SATA 1 SATA interface
- CapacityUp to 8TB capacity for each disk
- USB Interface 2 × USB 2.0
- Alarm In/Out N/A (4/1 is optional)
- General
- Power Supply 12 VDC or ≤ 18 W
- Consumption ≤ 10 W (without enabling PoE)
- Working Temperature -10 to +55º C (+14 to +131º F)
- Working Humidity 10 to 90 %
- Dimension (W × D × H)263 × 223 × 48 mm (10.34″ × 8.76″ × 1.87″)
- ≤ 1.5 kg (3.3 lb)
